Add-on and FMC Cards

FMC Cards

The FPGA Mezzanine Card (FMC) is a standard form factor to interface I/O mezzanine add-on cards to an FPGA or FPGA/SoC Module.

Drive Control

FMC card Application Features
FMC DR2
FMC DR2 Drive Control Card Evaluation / rapid prototyping / low-volume series 6 half bridges, 18A @ 42V, current sense, encoder and hall interfaces, break chopper, CAN transceiver, 30V I/O
FMC AN1
FMC AN1 add on Card Evaluation / rapid prototyping / low-volume series FMC to standard pin header adapter.

Add-on Cards

Communication

Add-on card Application Features
EIO-SFP1
EIO-SFP1 communication add-on Card Evaluation / rapid prototyping / low-volume series PCIe x16 edge connector, 2 SFP+ slots, 4 MGT channels on SMA connectors, 2 SATA connectors
